Heat Transfer Aluminum Strip Sheet
Home » Products » Heat Transfer Aluminum Material » Heat Transfer Aluminum Strip Sheet

TaiXing Aluminum supply the whole range of products heat transfer unclad aluminum strip sheet, plain and coated material to the various processes for brazing or mechanically joining of heat exchangers.

Our products are of the highest quality to meet the developing and demanding requirements of the market, i.e. improved strength, sag resistance, corrosion resistance.

Aluminum strip sheet are widely used for manufacturing of various kinds of Heat Exchangers; Air Conditioner; Condensers; Evaporators; Engine Cooling; Radiators; Heater Cores; Charge Air Coolers, Intercoolers; Engine Oil Coolers / Transmission Oil Coolers and so on.

Specifications of Heat Transfer Aluminum Strip Sheet

Name

Alloy

Specification

Application

Aluminum Fin Material
H16 /H14

Unclad Aluminum Fin Strip Sheet

3003+1.5%Zn, 3003+1.5%Zn+Zr

Thickness: 0.05~0.35mm
Width: 10mm

Fin for Heat Radiator of Automobile and Power Station

Cladding Aluminum Fin Strip Sheet

Core Materiall: 3003+1.5%Zn
Cladding Material: 4343

Tube Material
(H16, H14/ H26, H24)

Unclad Aluminum Tube Strip Sheet

3003

Thickness: 0.2-0.5mm
Width: 26-200mm

Aluminum Tube Material for Automobile Tank

Cladding Aluminum Tube Strip Sheet

Core Material: 3003
Cladding Material: 4343/ 7072

Header / Side Plate (O Temper)

Cladding Aluminum Fin Strip Sheet

Core Material: 3003
Cladding Material: 4343(both side)

Thickness: 1.0-2.5mm
Width: 30~1400mm
Plate Length: 1000~6000mm

Header / side Plate for Automobile Tank

Unclad Aluminum Tube Strip Sheet

3003

Heat Collector Tube
(H14)

Core Material: 3003
Cladding Material: 4045 (one side)

Thickness: 1.0~2.0mm

Automobile Air Conditioning Manifold

Evaporator Tube Sheet Material

Core Material: 3003
Cladding Material 1/2: 4343/4343

Thickness: 0.4-0.6mm
Width: 30~1400mm

Laminated Evaporator

Unclad Aluminum Strip Sheet Physical Property Data

Alloy

Temper

Thickness
(mm)

Tolerance
(mm)

Clad Ratio
(%)

Tensile
Strength
(MPa)

Yield
Strength
(MPa)

Elongation
(%)
Min

Application

3003

H14

0.08~0.12

±0.005

None

150~200

≥120

1

Evaporator Fin and Plate

3003

H26

0.3~0.35

±0.015

None

190~220

≥160

8

Glass Mounting Bracket Material

3003

H14

0.06~0.1

±0.005

None

150~200

≥120

1

Radiator Fin and Plate

4343/3003/4343

H14

0.06~0.1

±0.005

8~12

150~200

≥120

1

4343/3003/4343

H14

0.08~0.12

±0.005

8~12

150~200

≥120

1

Parallel Condenser Fin

4343/3003/4343

H14

0.1~0.12

±0.005

8~12

150~120

≥120

1

Charge Air Cooler Material

4045/3003/4045

H14

0.1~0.12

±0.005

8~12

150~200

≥120

1

1060

O

0.35~0.4

±0.02

None

55~95

≥15

25

Air Cooling Fin Material for Tubes

1100

O

0.35~0.4

±0.02

None

75~105

≥25

25

3003

O

0.2~0.3

±0.01

None

100~150

≥45

15

Aluminium for Heating Element

3003

H16

0.5~0.7

±0.02

None

150~210

≥120

1

4047

H18

0.05~0.1

±0.005

None

≥200

≥170

0.5

4047

O

0.4~0.5

±0.02

None

80~140

≥35

12

Welding Wire

7072

H19

0.12~0.15

±0.005

None

145~172

≥15

0.5

Fin Stocks

4A13

H18

0.05~0.1

±0.005

None

≥190
